| Superior RF performance，high efficiency | High Gain and low Noise Figure |
| Operating frequency can be customized | Advanced PA technology，high stability and reliability |
| Easy installation，operation and maintenance | Flexible to any environment and low cost |
TECHNICAL PARAMETERS
Items | Parameters | |
| Downlink | Uplink | |
| Frequency Range | 163.2MHz～165.2MHz | 156.5MHz～158.5MHz |
| Output Power（Max） | 37±1dBm(Total) | 30±1dBm(Total) |
| Max Gain | 85±3dB | 85±3dB |
| Number of Channels | 8 | |
| Gain Modulation Range | 30dB | |
| Gain Modulation Step | 1dB | |
| Gain Modulation Error | While gain is 0-20dB,Error≤1dB;While gain is 21-30dB,Error≤1.5dB | |
| Noise Factor | ≤5dB | ≤5dB |
| Max NO Damage Input Power | -10dBm | -10dBm |
| Automatic Level Control（ALC） | Output power variation < 2dB or be off when adding 10dB at max output power. Control range≥30dB | |
| Pass Band Ripple | ≤3dB | |
| VSWR | ≤2.0 | |
| Time Delay | ≤6.0μs | |
| Spurious Emissions(In-Band) | ≤-36dBm/30kHz | |
| Spurious Emissions(Out-Band) | 9kHz～1GHz：≤-36dBm | 1GHz～12.75GHz：≤-30dBm |
| IMD(In-Band) | ≤-36dBm/30kHz | |
| IMD(Out-Band) | 9kHz～1GHz：≤-36dBm | 1GHz～12.75GHz：≤-30dBm |
| Frequency Stability | ≤0.05ppm | |
| Out of band Gain | ≤50dB@400kHz ≤40dB@600kHz ≤35dB@1MHz ≤25dB@5MHz | |
| Local Monitoring & Control | RS232 | |
| RF Connection Mode | N/F,50Ω | |
| Power Supply Mode | The Power adapter, In: AC 100V~260V,45~55Hz; Out: 9V/5A; | |
| Power Consumption | ≤220W | |
| Operation Temperature | -25℃ ～ +50℃ | |
| Storage Temperature | -40℃ ～ +85℃ | |
| Mounting | Wall Mounted, IP55 | |
| Machine Weight | ≤20kg | |
| Dimension | 357mm×217mm×453mm （W*H*L） | |
| MTBF | ≥100000h | |
