| Superior RF performance，high efficiency | High Gain and low Noise Figure |
| Operating frequency can be customized | Advanced PA technology，high stability and reliability |
| Easy installation，operation and maintenance | Flexible to any environment and low cost |
TECHNICAL PARAMETERS
Items | Parameters | |
| Downlink | Uplink | |
| Frequency Range | 164.9MHz～165.4MHz | 160.1MHz～160.6MHz |
| Output Power（Max） | 27±2.0dBm | -2±2.0dBm |
| Max Gain | 45±3dB | 45±3dB |
| Gain Modulation Range | 30dB | |
| Gain Modulation Step | 1dB | |
| Gain Modulation Error | While gain is 0-20dB,Error≤1dB;While gain is 21-30dB,Error≤1.5dB | |
| Noise Factor | / | ≤5dB |
| Max NO Damage Input Power | 10dBm | -10dBm |
| Automatic Level Control（ALC） | Output power variation < 2dB or be off when adding 10dB at max output power. | |
| Pass Band Ripple | ≤3dB | |
| VSWR | ≤1.5 | |
| Time Delay | ≤1.5μs | |
| Spurious Emissions(In-Band) | ≤-36dBm/30kHz | |
| Spurious Emissions(Out-Band) | 9kHz～1GHz：≤-36dBm | 1GHz～12.75GHz：≤-30dBm |
| IMD(In-Band) | ≤-36dBm/30kHz | |
| IMD(Out-Band) | 9kHz～1GHz：≤-36dBm | 1GHz～12.75GHz：≤-30dBm |
| Frequency Stability | ≤0.05ppm | |
| Out of band Gain | ≤50dB@400kHz ≤40dB@600kHz ≤35dB@1MHz ≤25dB@5MHz | |
| Local Monitoring & Control | Local RS232 | |
| Type of Fiber Optical Cable | Single Mode | |
| Fiber Optical Interface | FC/APC | |
| Fiber Optical Loss | Max 8dBo | |
| Optical Wavelength | 1310nm/1550nm | |
| Optical Receiving Sensitivity | -15dBm | |
| Optical Transmission Power | 3±2.0dBm | |
| Casing class | IP65 | |
| RF Connection Mode | N/F,50Ω | |
| Power Supply Mode | The Power adapter, In: AC 100V~260V,45~55Hz; &DC -48V | |
| Power Consumption | ≤80W | |
| Operation Temperature | -25℃ ～ +50℃ | |
| Storage Temperature | -40℃ ～ +85℃ | |
| Mounting | Wall Mounted | |
| Machine Weight | ≤20kg | |
| Dimension | 530*400*200mm （W*H*L） | |
| MTBF | ≥100000h | |
